Standing Seam
ROOFING, FACADE, SOFFIT.
The standing seam system, which is used for roofing, façade, and soffit, combines classic European craftsmanship with modern performance. Designed for versatility, it suits curves, angles, and complex forms with a sleek, seamless finish. Made from COLORBOND® steel and other premium metals, like zinc, aluminum, and copper, it delivers lasting strength and style in all conditions.
KEY FEATURES:
- PANELS ARE 25-38MM RIB HEIGHTS AND 100-530MM WIDE, OFFERING FLEXIBILITY FOR ANY DESIGN.
- SUITABLE FOR CURVED, CONICAL, CONVEX, AND CONCAVE APPLICATIONS.
- ENABLES A SEAMLESS ROOF-TO-WALL TRANSITION FOR A CLEAN, CONTINUOUS LOOK.
- INSTALLABLE IN CROSS-SEAMED OR CONTINUOUS PANELS.
- FIXED CLIPS 150MM FROM TOP OF PANEL AND SLIDING CLIPS EVERY 400MM FOR EXPANSION/MOVEMENT.
- ORIENTATION OPTIONS: VERTICAL, HORIZONTAL, OR DIAGONAL.
OUR PACKAGE:
WE PROVIDE A FULL END-TO-END SERVICE, INCLUDING:
- SUPPLY AND INSTALLATION OF BATTENS/TOP HATS.
- STRAIGHTENING AND PACKING OF EXTERNAL WALLS/ROOF.
- INSTALLATION OF 15-19MM STRUCTURAL PLYWOOD SUBSTRATE
- SUPPLY AND INSTALL OF PROCTORWRAP BREATHABLE MEMBRANE.
- SUPPLY & INSTALLATION OF METAL CLADDING.
Robust Protection For Diverse Builds
The mix of coastal air, harsh sunlight, and unpredictable temperature swings slowly wears down most architectural materials. Paint fades, fixings loosen, and repairs become routine. A reliable cladding can safeguard your building's exterior, bringing down the restoration costs. At MetalKladding Group, we rely on various profiles, including the Standing Seam, known explicitly to stand up against adverse weather conditions.
It is an installation method designed in Europe to achieve clean aesthetics with concealed fixings, fine tolerances, and long panel runs. In Australia, our team re-engineers it as per the local terrain with corrosion-resistant alloys, increasing clip strength, and UV-resistant paints. These adjustments ensure endurance under harsh weather conditions and provide additional strength to the framework.
Advantages of Standing Seam Cladding Installations
Once installed, standing seam claddings form a protective metal covering that deflects the harsh effects of rain, wind, and UV so the building underneath stays safe and dry. Using it provides a range of benefits, including:
- High resistance to corrosion, fire, and thermal expansion
- Minimal upkeep and a lifespan that comfortably outlasts most coatings
- Suitability to complex geometries, including curves, slopes, or vertical façades
- Apt for facades and roofings alike
Applications
- Residential: Used for façades, roofing, and soffits, to give a clean, defined look that stands up well in coastal or high-exposure areas.
- Commercial: Ideal for office buildings, retail façades, schools, and hospitality spaces, where consistency and durability matter.
- Industrial: Perfect for warehouses, transport hubs, and processing facilities, where long spans and minimal maintenance are priorities.
Tailor Installations For Contemporary Architecture
Our team utilises different types of standing seam claddings as per the project’s structure, scale, and exposure. These include:
- Single-Lock Seam
- Double-Lock Seam
- Snap-Lock Seam
We use a wide range of metals including aluminium, zinc, copper, and steel (COLORBOND® finishes).
If you’d like to see the materials firsthand, visit our Melbourne showroom. You can feel the seams, compare finishes under natural light, and talk through design options with the team that builds and installs them every day.
Frequently Asked Questions
A fixed time cannot be stated because it will vary depending on the expansiveness of the property and cladding requirements. A few other things that will matter are:
- Design complexity
- Site accessibility
- Building height
- Weather conditions during installation
Our team will provide you with a timeframe after assessing the above conditions.
Yes, it can be, and it's quite a popular approach, especially when looking to upgrade Melbourne houses. We assess the structure to ascertain its suitability. Once confirmed, we use the standing seam cladding to:
- Refresh the overall look of the building.
- Add an extra layer of protection.
- Bring in a more contemporary finish.
Before proceeding, we assess the structure to ensure everything integrates properly and performs as intended.
Our team ensures there is a solid base for the panels to remain aligned and secure over time. Depending on the building type, these substructures can include:
- Plywood or another form of continuous backing
- Battens or support rails for fixing
- Adequate spacing to allow ventilation and drainage
The cladding can and cannot change depending on the material chosen. For example, some metals, like zinc, copper and weathered steel, are designed to evolve, whereas aluminium and COLOURBOND steel are designed to resist fading.
In the end, it is less about right or wrong, and more about whether you prefer a finish that stays the same or one that gradually develops over time.
Standing seam cladding is defined by its raised vertical seams and concealed fixings. This creates a clean, uninterrupted surface without visible fasteners.
Compared to other systems, it offers:
- A more refined and uniform appearance
- Reduced risk of water ingress
- Better accommodation of thermal movement
This makes it a preferred option for projects where both performance and finish matter.
